G-SENS Proximity Sensors

G-SENS Industrial Proximity Sensors - Inductive & Capacitive


G-SENS proximity sensors are advanced non-contact sensing devices designed to detect the presence or absence of objects without physical contact, making them indispensable components in modern industrial automation and control systems. These sensors leverage various sensing principles, including **inductive, capacitive, and photoelectric technologies**, to cater to a wide range of detection needs. Inductive proximity sensors, for instance, are highly effective in detecting metallic objects, while capacitive sensors can sense both metallic and non-metallic materials, including liquids and powders. Photoelectric sensors, on the other hand, use light to detect objects, offering longer sensing ranges and the ability to detect objects of varying colors and textures. This versatility allows GSENS proximity sensors to be seamlessly integrated into diverse applications, from packaging and material handling to assembly lines and robotics, providing precise and reliable feedback for automated processes.

The robust construction and high performance of GSENS proximity sensors contribute significantly to enhanced operational efficiency and reduced downtime in industrial environments. Designed to withstand harsh conditions, including dust, moisture, and temperature fluctuations, these sensors offer exceptional durability and a long operational lifespan. Their non-contact operation minimizes wear and tear, further extending their service life and reducing maintenance requirements. By providing accurate and rapid detection, GSENS proximity sensors enable precise control over machinery and processes, leading to improved product quality, increased throughput, and enhanced safety for personnel and equipment. This makes them a critical investment for any business seeking to optimize its automation capabilities and achieve greater productivity.



DC INDUCTIVE PROXIMITY SENSOR - 3 WIRE, 10-30V DC, 2 METER CABLE ("CE" Approved)

PRODUCT IMAGE CAT NO. DESCRIPTION
M04 Inductive Proximity Sensor, Threading Type, Flush GR04 (F)
THREADING TYPE
M04 INDUCTIVE PROXIMITY SWITCH THREADING TYPE, **FLUSH MOUNT**
M05 M06 Inductive Proximity Sensor, Threading Type GR05/GES06(F)
THREADING TYPE
M05 / M06 INDUCTIVE PROXIMITY SWITCH THREADING TYPE
M08 Inductive Proximity Sensor, 1MM Sensing, Flush Mount GR-08
/DP/DN/DPN/DNN(F)
M08 **PNP NO** / **NPN NO** / **PNP NC** / **NPN NC**, **FLUSH**
1 MM SENSING
M08 Inductive Proximity Sensor, 2MM Sensing, Non-Flush GR-08
/DP/DN/DPN/DNN(NF)
M08 **PNP NO** / **NPN NO** / **PNP NC** / **NPN NC**, **NON-FLUSH**
2 MM SENSING
M12 Inductive Proximity Sensor, 2MM Sensing, Flush Mount GR-12
/DP/DN/DPN/DNN(F)
M-12 PNP NO / NPN-NO/
PNP-NC / NPN-NC **FLUSH** 2 MM SENSING
M12 Inductive Proximity Sensor, 4MM Sensing, Non-Flush GR-12
/DP/DN/DPN/DNN(NF)
M-12 PNP NO / NPN-NO/
PNP-NC / NPN-NC **NON-FLUSH** 4 MM SENSING
M18 Inductive Proximity Sensor, 4MM Sensing, Flush Mount GR-18
/DP/DN/DPN/DNN(F)
M-18 PNP NO / NPN-NO/
PNP-NC / NPN-NC **FLUSH** 4 MM SENSING
M18 Inductive Proximity Sensor, 8MM Sensing, Non-Flush GR-18
/DP/DN/DPN/DNN(NF)
M-18 PNP NO / NPN-NO/
PNP-NC / NPN-NC **NON-FLUSH** 8 MM SENSING
M30 Inductive Proximity Sensor, 10MM Sensing, Flush Mount GR-30
/DP/DN/DPN/DNN(F)
M-30 PNP NO / NPN-NO/
PNP-NC / NPN-NC **FLUSH** 10 MM SENSING
M30 Inductive Proximity Sensor, 15MM Sensing, Non-Flush GR-30
/DP/DN/DPN/DNN(NF)
M-30 PNP NO / NPN-NO/
PNP-NC / NPN-NC **NON-FLUSH** 15 MM SENSING

G-SENS AC INDUCTIVE PROXIMITY SENSOR - 2 WIRE, 90-270V AC, 2 METER CABLE

PRODUCT IMAGE CAT NO. DESCRIPTION
M08 AC Inductive Proximity Sensor, Non-Flush, 2MM GR-08 A/O / AC (NF) M08 AC NO / AC NC **NON-FLUSH**
2 MM SENSING
M08 AC Inductive Proximity Sensor, Flush, 1MM GR-08 A/O / AC (F) M08 AC NO / AC NC **FLUSH**
1 MM SENSING
M12 AC Inductive Proximity Sensor, Non-Flush, 4MM GR-12 A/O / AC (NF) M12 AC NO / AC NC **NON-FLUSH**
4 MM SENSING
M12 AC Inductive Proximity Sensor, Flush, 2MM GR-12 A/O / AC (F) M12 AC NO / AC NC **FLUSH**
2 MM SENSING
M18 AC Inductive Proximity Sensor, Non-Flush, 8MM GR-18 A/O / AC (NF) M18 AC NO / AC NC **NON-FLUSH**
8 MM SENSING
M18 AC Inductive Proximity Sensor, Flush, 4MM GR-18 A/O / AC (F) M18 AC NO / AC NC **FLUSH**
4 MM SENSING
M30 AC Inductive Proximity Sensor, Non-Flush, 15MM GR-30 A/O / AC (NF) M30 AC NO / AC NC **NON-FLUSH**
15 MM SENSING
M30 AC Inductive Proximity Sensor, Flush, 10MM GR-30 A/O / AC (F) M30 AC NO / AC NC **FLUSH**
10 MM SENSING

G-SENS SQUARE INDUCTIVE PROXIMITY SENSOR - 10/30V DC, 3 WIRE

PRODUCT IMAGE CAT NO. DESCRIPTION
GN-05-DN Square Inductive Proximity Sensor, Adjustable GN-05-DN 17*35 MM PNP NO / NPN NO
5 MM SENSING **ADJUSTABLE**
GL-Q5MF1 Square Inductive Proximity Sensor GL-Q5MF1 17*28 MM PNP NO / NPN NO
5 MM SENSING

INDUCTIVE PROXIMITY SENSOR - DC 2 WIRE, 10-30 VDC, 2 Mtrs. CABLE

PRODUCT IMAGE CAT NO. DESCRIPTION
DC 2-Wire Inductive Proximity Sensor Series GR-12-DO (NF) / (F) M12 DC NO TYPE **NON-FLUSH** 4 MM / **FLUSH** 2 MM SENSING
GR-12-DN (NF) / (F) M12 DC NC TYPE **NON-FLUSH** 4 MM / **FLUSH** 2 MM SENSING
GR-182-DO (NF) / (F) M18 DC NO TYPE **NON-FLUSH** 4 MM / **FLUSH** 2 MM SENSING
GR-182-DN (NF) / (F) M18 DC NC TYPE **NON-FLUSH** 4 MM / **FLUSH** 2 MM SENSING

INDUCTIVE PROXIMITY SENSOR - CONNECTOR TYPE, 10-30 VDC

PRODUCT IMAGE CAT NO. DESCRIPTION
M08 to M30 Connector Type Inductive Sensors GR-08-DPC/DNC (NF) M 08 PNP NO **NON-FLUSH** / NPN NO **NON-FLUSH**, 2MM SENSING, 3 PINS
GR-08-DPC/DNC (F) M 08 PNP NO / NPN NO **FLUSH**, 1 MM SENSING, 3 PINS
GR-12-DPC/DNC (NF) M 12 PNP NO / NPN NO **NON-FLUSH**, 4MM SENSING, 4 PINS
GR-12-DPC/DNC (F) M 12 PNP NO / NPN NO **FLUSH**, 2 MM SENSING, 4 PINS
GR-18-DPC/DNC (NF) M 18 PNP NO / NPN NO **NON-FLUSH**, 8MM SENSING, 4 PINS
GR-18-DPC/DNC (F) M 18 PNP NO / NPN NO **FLUSH**, 5 MM SENSING, 4 PINS
GR-30-DPC/DNC (NF) M 30 PNP NO / NPN NO **NON-FLUSH**, 15MM SENSING, 4 PINS
GR-30-DPC/DNC (F) M 30 PNP NO / NPN NO **FLUSH**, 10 MM SENSING, 4 PINS

SPARE CONNECTORS FOR M12 / M18 / M30 SENSORS - 2 MTR CABLE

PRODUCT IMAGE DESCRIPTION
M12 Straight Sensor Connector STRAIGHT TYPE CONNECTOR
M12 Angular Sensor Connector ANGULAR TYPE CONNECTOR

G-SENS PHOTOELECTRIC SENSOR - 10-30 DC, METAL BODY

PRODUCT IMAGE CAT NO. DESCRIPTION
G-SENS Diffuse Scan Photoelectric Sensor GPC12 DP PNP NO, THREAD TYPE, 3 WIRE, 80MM SENSING SENSOR
GPC12 DN NPN NO, THREAD TYPE - 3 WIRE, 80 MM SENSING SENSOR
GPC018 DP-500 M-18 PNP (NO+NC), 100MM Sensing - 4 Wire Type SENSOR
DPC-18 DN 500 M-18 **NPN** (NO+NC), 100MM Sensing - 4 Wire Type SENSOR
DPC-30 DP-1000 M-30 PNP (NO+NC), 1000 MM Sensing - 4 Wire Type SENSOR
DPC-30 DN-1000 M-30 NPN (NO+NC), 1000 MM Sensing - 4 Wire Type SENSOR
DPC-18-AO M-18 AC NO (90-270VAC), 500 MM Sensing - 2 Wire SENSOR
DPC-30-AO M-30 AC NO (90-270VAC), 1000 MM Sensing - 2 Wire SENSOR

G-SENS THROUGH BEAM PHOTOCELL - 10-30V DC, 4 WIRE SENSOR

PRODUCT IMAGE CAT NO. DESCRIPTION
G-SENS Through Beam Photoelectric Sensor GPC18 DPNT 4 WIRE, 10-30 DC, PNP NO + NC, 5MTR SENSING DISTANCE
GPC18 DNNT 4 WIRE, 10-30 DC, **NPN** NO + NC, 5MTR SENSING DISTANCE
